New to the duet COMPLETE NEWBIE
-
Please post your current config.g and homeall.g and copy and paste the first 50 lines or so of your sliced gcode file you're trying to print.
-
; Configuration file for Duet WiFi (firmware version 3)
; executed by the firmware on start-up
;
; generated by RepRapFirmware Configuration Tool v3.2.1 on Tue Jan 19 2021 17:33:25 GMT-0500 (Eastern Standard Time); General preferences
G90 ; send absolute coordinates...
M83 ; ...but relative extruder moves
M550 P"Creola" ; set printer name; Network
M552 S1 ; enable network
M586 P0 S1 ; enable HTTP
M586 P1 S0 ; disable FTP
M586 P2 S0 ; disable Telnet; Drives
M569 P0 S0 ; physical drive 0 goes backwards
M569 P1 S0 ; physical drive 1 goes backwards
M569 P2 S1 ; physical drive 2 goes forwards
M569 P3 S0 ; physical drive 3 goes backwards
M584 X0 Y1 Z2 E3 ; set drive mapping
M350 X16 Y16 Z16 E16 I1 ; configure microstepping with interpolation
M92 X80.00 Y80.00 Z400.00 E97.08 ; set steps per mm
M566 X900.00 Y900.00 Z60.00 E120.00 ; set maximum instantaneous speed changes (mm/min)
M203 X6000.00 Y6000.00 Z600.00 E1200.00 ; set maximum speeds (mm/min)
M201 X500.00 Y500.00 Z120.00 E250.00 ; set accelerations (mm/s^2)
M906 X800 Y800 Z800 E800 I30 ; set motor currents (mA) and motor idle factor in per cent
M84 S30 ; Set idle timeout; Axis Limits
M208 X0 Y0 Z0 S1 ; set axis minima
M208 X300 Y300 Z400 S0 ; set axis maxima; Endstops
M574 X1 S1 P"xstop" ; configure active-high endstop for low end on X via pin xstop
M574 Y1 S1 P"ystop" ; configure active-high endstop for low end on Y via pin ystop
M574 Z1 S1 P"!zstop" ; configure active-high endstop for low end on Z via pin !zstop; Z-Probe
M558 P0 H18 F120 T480000 ; disable Z probe but set dive height, probe speed and travel speed
M557 X10:220 Y10:220 S20 ; define mesh grid; Heaters
M308 S0 P"bedtemp" Y"thermistor" T98801 B4185 ; configure sensor 0 as thermistor on pin e0temp
M950 H0 C"bedheat" T0 ; create bed heater output on e0heat and map it to sensor 0
M307 H0 B0 S1.00 ; disable bang-bang mode for the bed heater and set PWM limit
M140 H0 ; map heated bed to heater 0
M143 H0 S80 ; set temperature limit for heater 0 to 80C
M308 S1 P"e1temp" Y"thermistor" T98801 B4185 ; configure sensor 1 as thermistor on pin e1temp; homeall.g
; called to home all axes
;
; generated by RepRapFirmware Configuration Tool v3.2.1 on Tue Jan 19 2021 17:33:25 GMT-0500 (Eastern Standard Time)
G91 ; relative positioning
G1 H2 Z18 F480000 ; lift Z relative to current position
G1 H1 X-305 Y-305 F3000 ; move quickly to X and Y axis endstops and stop there (first pass)
G1 H2 X5 Y5 F480000 ; go back a few mm
G1 H1 X-305 Y-305 F3600 ; move slowly to X and Y axis endstops once more (second pass)
G1 H1 Z-405 F3600 ; move Z down stopping at the endstop
G90 ; absolute positioning
G92 Z0 ; set Z position to axis minimum (you may want to adjust this); Uncomment the following lines to lift Z after probing
;G91 ; relative positioning
;G1 Z18 F8000 ; lift Z relative to current position
;G90 ; absolute positioning;FLAVOR:Marlin
;TIME:15708
;Filament used: 30.0079m
;Layer height: 0.32
;MINX:87.5
;MINY:87.5
;MINZ:0.32
;MAXX:212.5
;MAXY:212.5
;MAXZ:99.84
;Generated with Cura_SteamEngine 4.8.0
M140 S45
M105
M190 S45
M104 S210
M105
M109 S210
M82 ;absolute extrusion mode
M201 X500.00 Y500.00 Z100.00 E5000.00 ;Setup machine max acceleration
M203 X500.00 Y500.00 Z10.00 E50.00 ;Setup machine max feedrate
M204 P500.00 R1000.00 T500.00 ;Setup Print/Retract/Travel acceleration
M205 X8.00 Y8.00 Z0.40 E5.00 ;Setup Jerk
M220 S100 ;Reset Feedrate
M221 S100 ;Reset FlowrateG28 ;Home
G92 E0 ;Reset Extruder
G1 Z2.0 F3000 ;Move Z Axis up
G1 X10.1 Y20 Z0.28 F5000.0 ;Move to start position
G1 X10.1 Y200.0 Z0.28 F1500.0 E15 ;Draw the first line
G1 X10.4 Y200.0 Z0.28 F5000.0 ;Move to side a little
G1 X10.4 Y20 Z0.28 F1500.0 E30 ;Draw the second line
G92 E0 ;Reset Extruder
G1 Z2.0 F3000 ;Move Z Axis upG92 E0
G92 E0
G1 F2700 E-5
;LAYER_COUNT:312
;LAYER:0
M107
G0 F6000 X96.919 Y97.136 Z0.32
;TYPE:SKIRT
G1 F2700 E0
G1 F1200 X97.194 Y96.861 E0.05174
G1 X97.565 Y96.502 E0.12042
G1 X97.79 Y96.289 E0.16164
G1 X98.257 Y95.859 E0.2461
G1 X98.563 Y95.587 E0.30057 -
@gabrealek said in New to the duet COMPLETE NEWBIE:
M201 X500.00 Y500.00 Z100.00 E5000.00 ;Setup machine max acceleration
M203 X500.00 Y500.00 Z10.00 E50.00 ;Setup machine max feedrate
M204 P500.00 R1000.00 T500.00 ;Setup Print/Retract/Travel acceleration
M205 X8.00 Y8.00 Z0.40 E5.00 ;Setup JerkDelete these lines from your cura start gcode.
@gabrealek said in New to the duet COMPLETE NEWBIE:
;FLAVOR:Marlin
Also in Cura change your gcode flavour to REPRAP
Also change cura to use relative extrusion while you're at it.
Then reslice and try again.
-
@Phaedrux I feel like such a nube, thanks again!! Im about to try now and keep you updated.
-
Don't feel too bad, 3D printing is probably one of the most complicated hobbies you can pick up.
-
@Phaedrux Okay. . so it tried to print again . . but . the extruder isnt going up or down . .
-
@gabrealek said in New to the duet COMPLETE NEWBIE:
M574 Z1 S1 P"!zstop" ; configure active-high endstop for low end on Z via pin !zstop
Is your Z endstop the same as the other endstops? Your config has it as inverted signal, which could cause it to act as triggered even when it's not, meaning your homing is off.
Does homeall work to move all axis to their endstops correctly? Are you then able to jog all axis around correctly?
-x to the left, +x to the right, -y moves head to front of bed, +y moves head back, -z moves nozzle towards bed, +z moves nozzle away from bed.
-
@Phaedrux im not able to move to any - axis. I was able to this morning and i havent unplugged anything. Should i go into my config and change that?
-
@gabrealek said in New to the duet COMPLETE NEWBIE:
G1 H2 X5 Y5 F480000 ; go back a few mm
In your homeall can you change this line from G1 H2 to remove the H2 completely?
What does it do when you tell it to home all?
Does it move towards the endstops?I'm not sure what you mean by not able to move to any - axis.
-
@Phaedrux whew . . Uhm so i went and took the "!" from in front of the zstop
M574 Z1 S1 P"zstop" ; configure active-high endstop for low end on Z via pin zstop
and now i'm able to move everything accordingly. It wouldn't let me use any of the negative machine movements. I dont know why it inverted it like that. . Do you think i should still go and remove the H2?
-
Yes, still remove the H2. Glad that
!took care of the homing. -
@Phaedrux i took off the H2 and it wouldnt let me home all it gave me
G28
Error: G0/G1: insufficient axes homedI put it back on and homed all again and it homed correctly . . . idk whats going on.
-
That's kind of why H2 shouldn't be in there. H2 will let it proceed even if there is a problem.
Looking at the printer from the front (so that the bed motor is at the rear) the 0,0 origin point should be the front left of the bed. -x should move to the left etc as I mentioned above.
We can test this without trying to home the printer first. Turn off the printer, move the print head and bed to the center point. Now turn the printer on and send g92 x150 y150 z1. Now you should be able to jog the axis around with the buttons to test that they move in the correct directions.
Then we need to know where the endetops are physically located on the cr10. IF it matches the ender3 the x should be on the left and y at the back by the motor. Is that right?
Then send m119 to get the status of the endstops. They should all say not triggered. And when you press them and send m119 it should say triggered.
-
; homeall.g
; called to home all axes
;
; generated by RepRapFirmware Configuration Tool v3.2.1 on Tue Jan 19 2021 17:33:25 GMT-0500 (Eastern Standard Time)
G91 ; relative positioning
G1 H2 Z18 F480000 ; lift Z relative to current position
G1 H1 X-305 Y-305 F3000 ; move quickly to X and Y axis endstops and stop there (first pass)
G1 H2 X5 Y5 F480000 ; go back a few mm
G1 H1 X-305 Y-305 F3600 ; move slowly to X and Y axis endstops once more (second pass)
G1 H1 Z-405 F3600 ; move Z down stopping at the endstop
G90 ; absolute positioning
G92 Z0 ; set Z position to axis minimum (you may want to adjust this); Uncomment the following lines to lift Z after probing
;G91 ; relative positioning
;G1 Z18 F8000 ; lift Z relative to current position
;G90 ; absolute positioningSo just the first H2 right?
-
@Phaedrux
1/21/2021, 4:54:38 PM m119
Endstops - X: not stopped, Y: not stopped, Z: at min stop, Z probe: at min stop -
@Phaedrux
yes. Z is still triggered .
-
Endstops - X: not stopped, Y: at min stop, Z: at min stop, Z probe: at min stop
Y is triggered but Z is not at the moment and it still reads as "triggered". .
-
@Phaedrux They are all moving correctly . im about to move it to the center to see if its still triggered. .
m119
Endstops - X: not stopped, Y: not stopped, Z: not stopped, Z probe: at min stopYAYYYYYY
-
@Phaedrux
1/21/2021, 5:04:08 PM G28
Error: G0/G1: insufficient axes homedDoes this mean i have to home them all individually at this point?
G1 (H1) Z18 F480000 ; lift Z relative to current position
would this work? -
@gabrealek said in New to the duet COMPLETE NEWBIE:
So just the first H2 right?
Nope, just the one for the XY axis move.
G1 H2 X5 Y5 F480000 ; go back a few mm
